Industrial By Design

Open Box

8-Foot Big Wheel Barn Door Hardware Kit from Industrial By Design Premium quality parts are provided along with the a completely turnkey experience. The result is the only 5-star kit among the competition. Our hardware kits are installed in thousands of homes nationwide, so we know the details our customers want and need to know for their project to go smoothly. INSIDE THE BOX 8-Foot Rail: A single rail includes six pre-drilled holes every 16" on center. Holes begin 8" on center from each end of the rail. Rail is constructed of solid 1/4" thick steel, finished with our highly durable powder coating. This gets baked onto the steel at 400 degrees and creates the strongest bond possible.   Rail Hardware: Six lag bolts (of the highest grade available) with washers and six rail spacers attach the rail securely to the studs, or header board, for supporting up to 225 pounds comfortably.   2 Hangers: These hangers are built with our premium nylon wheels, which are often an expensive upgrade at other shops. We made these the standard wheel for all our kits, and have tested our finished hangers beyond 100,000 rolls. Two different sets of bolts for attaching hangers to the door are included in order to accommodate doors ranging from 1 1/4" to 1 3/4" thick.   2 Door Stoppers: Two door stoppers slide along the rail and tighten down at any point to stop your door exactly where you want, and they’re cushioned by rubber caps for a quiet close.   Floor Guide: A T-shaped floor guide is supplied (with anchors) to prevent the door from swinging out or up against the baseboard. INCLUDES INSTALLATION VIDEO We include these detailed measurements and installation tips in our step-by-step video tutorial and written instructions. In addition, our experienced U.S. based professionals, who have actually installed our kits, are happy to help on topics ranging from the planning to installation of your project. FAQ Q: What if my studs don't line up with the pre-drilled holes in the rail? A: Simply attach a 1" thick header board into your studs first, and then the rail can attach anywhere into the header board. Many customers prefer this look anyway. Customers have painted the header to match the wall color to blend in, or to match the door. Q: How thick of a door will this kit work with? ? A: There are solutions for any thickness of door! The bolts included for attaching the hangers to the door support a thickness range of 1 1/4" to 1 3/4", but this can be easily navigated by countersinking the bolt head into the back side of the door, or by picking up 4 longer bolts from your local hardware store. The other thing affected by a thicker door is the spacing needed between the door and wall (or baseboard/doorway trim). Plug in your door depth and trim depth below:  2 3/16" - door depth - trim depth - 3/16" (recommended gap from door to trim/wall) If your answer is 0 or greater, then you're fine. If your answer was negative, then that number is the extra spacing you need. This extra spacing is accomplished by bolting a header board to the studs, and then the rail to this header board. Also note that if your door is thicker than 2" thick, the top of your door could interfere with the bottom of the header. For this reason, it's advised to install the lags for your rail either 1" from the bottom of the header, or to install your hangers higher on the door to compensate for the header.   Q: How much space do I need above the doorway? A: You will need a minimum of 8" from the top of your door to the ceiling (or crown moulding, if any) for this kit to fit correctly. Q: Can I cut this rail down to the exact size I need? A: Absolutely! We recommend using an angle grinder or reciprocating saw.

BDH8SINGLEBIG

BHL00091444

21.5 pounds

Open Box

500 W Main St, Hendersonville TN 37075
