MeanWell

Brand New

348W 12V 29A Single Output Switchable Power Supply 12 Volts 29 Amps Features • AC input range selectable by a switch • Withstand 300 VAC surge input for 5 seconds • No load power consumption • 1U low profile • High operating temperature, up to 70°C • Protections: Short circuit / Overload / Over voltage / Over temperature • Built-in cooling fan, ON-OFF control • Compliance to UL 60950-1 • Withstand 5G vibration test • High efficiency, long life and high reliability • LED indicator for power on • 100% full load burn-in test • 3 year warranty Applications • Industrial automation machinery • Industrial control system • Mechanical and electrical equipment • Electronic instruments, equipment or apparatus Related Products • LRS-350-3.3 (3.3V 60A, 198W) Jameco P/N: 2219778 • LRS-350-4.2 (4.2V 60A, 252W) Jameco P/N: 2219786 • LRS-350-5 (5V 60A, 300W) Jameco P/N: 2219794 • LRS-350-15 (15V 23.2A, 348W) Jameco P/N: 2219815 • LRS-350-24 (24V 14.6A, 350.4W) Jameco P/N: 2219823 • LRS-350-36 (36V 9.7A, 349.2W) Jameco P/N: 2219831 • LRS-350-48 (48V 7.3A, 350.4W) Jameco P/N: 2219840 • LRS-150 Series (150 Watt, Enclosed Switchable Single Output Power Supply) • LRS-150F Series (150 Watt, Full Range Input Enclosed Switching Power Supply) • LRS-200 Series (200 Watt, Enclosed Switchable Single Output Power Supply) Detailed Specifications: • Primary Output Voltage (VDC): 12 • Output Current (A): 29 • Maximum Output Power (W): 350 • Family: LRS-350 • Input Voltage (VAC): 90 to 132, 180 to 264 • Input Frequency: 47 to 63 • Maximum Input Current (A): 6.8 • Output Connector Type: Screw Terminal Block • Number of Outputs: 1 • Product Type: AC to DC Power Supply (more.).

LRS-350-12

WEB30239135

4.8 inches

1.4 inches

1.7 pounds

9.6 inches

Brand New

1825 Webster Street, Dayton OH 45414

PAST PICK UP
